MKT Spec MAG 321CUP QD-OLED Website Name MAG 321CUP QD-OLED Color ID1/Black-Black Local Dimming NA Display Screen Size 31.5" (80 cm) Active Display Area (mm) 699.48(H) x 394.73(V) Curvature Curve 1700R Panel Type QD-OLED Resolution 3840x2160 (UHD) Pixel pitch (mm) 0.1814(H)x0.1814(V) Aspect Ratio 16:9 Dynamic Refresh Rate technology Adaptive-Sync Dynamic Refresh Rate Activated Range 48~165Hz HDR (High dynamic range) HDR True Black 400 SDR Brightness (nits) 250 HDR Brightness (Peak nits) 1000 Contrast Ratio 1500000:1 DCR (Dynamic Contrast Ratio) NA Signal Frequency 30~390 KHz(H) / 48~165 Hz(V) Refresh Rate 165HZ Response Time (MPRT) NA Response Time (GTG) 0.03ms Response Time (Tr + Tf) 0.1ms View Angles 178°(H)/178°(V) NTSC (CIE1976 area percentage/overlap) 120.5%/93.8% NTSC (CIE1931 area percentage/overlap) 103.6%/91.5% sRGB (CIE1976 area percentage/overlap) 138.2%/100% sRGB (CIE1931 area percentage/overlap) 146.2%/100% Adobe RGB (CIE1976 area percentage/overlap) 118.4%/97.5% Adobe RGB (CIE1931 area percentage/overlap) 108.4%/94% DCI-P3 (CIE1976 area percentage/overlap) 110.1%/99% DCI-P3 (CIE1931 area percentage/overlap) 107.8%/98.4% Rec.709 (CIE1976 area percentage/overlap) 138.2%/100% Rec.709 (CIE1931 area percentage/overlap) 146.2%/100% Rec.2020 (CIE1976 area percentage/overlap) 80.2%/80.2% Rec.2020 (CIE1931 area percentage/overlap) 77.3%/77.3% Quantum Dot Film NA Surface Treatment Anti-Reflection Touch Screen Non-touch Display Colors 1.07B Color bit 10 bits Note_DP 3840 x 2160 (Up to 165Hz) Note_HDMI 3840 x 2160 (Up to 165Hz) Note_DVI N/A VESA DisplayHDR VESA ClearMR Delta E I/O Ports HDMI 2 HDMI version 2.1 HDMI HDCP version 2.3 DisplayPort 1 DisplayPort version 1.4a DisplayPort HDCP version 2.3 Thunderbolt NA Thunderbolt version NA Thunderbolt HDCP version NA USB Type C (DisplayPort Alternate) 1 DVI NA D-Sub NA Line-in NA Mic-in NA Mic-in upstream NA Headphone-out 1 Audio Combo NA USB 2.0 Type A NA USB 2.0 Type B NA USB 2.0 Type C NA USB 3.2 Gen 1 Type A NA USB 3.2 Gen 1 Type B NA USB 3.2 Gen 1 Type C NA USB 3.2 Gen 2x2 Type C NA USB 3.2 Gen 2x2 Type A NA Card reader NA Lock type Kensington Lock Speaker NA Webcam NA Lan Port Power Country EU Territory EU Entity EU OBD Power Type Internal Power Board Power Input 100~240V, 50/60Hz On-mode Power Consumption (KWh/1000h) 50 Annual Energy Consumption (KWh) 140 Standby-mode Power Consumption (W) 0.5 Off-mode Power Consumption (W) 0.3 Energy Efficiency Rating G Adapter's KC safety Number NA Power Cord Type C13 QC Output NA QC Output Power NA PD Output Type C PD Output Power 15W Warranty Warranty 36M Design Adjustment (Tilt) -5° ~ 15° Adjustment (Swivel) -30° ~ 30° Adjustment (Height) 0 ~ 100 mm Adjustment (Pivot) NA VESA Mounting 100x100mm Frameless Design Yes Console Mode YES HDMI CEC YES Firmware Update YES Stand Attachment Method Stand Type Stand with Integrated Mini PC Mount KVM Version PIP/PBP Optix Scope Smart Crosshair Remote Display AI Gaming MSI OLED Care Scaler FW Update Carton Carton Item (SG14) SG14-M1S204A-MNT pcs/Carton 1 Pallet pallet Q'ty (by air) pcs 14 Q'ty/20cy (by air) pcs 140 Q'ty/40cy (by air) pcs 294 Dimension (L)(by air) mm 1200 Dimension (W)(by air) mm 1000 Dimension (H)(by air) mm 1348 Net Weight (by air) kg 158.2 Gross Weight (by air) kg 175.94 pallet Q'ty (by sea) pcs 24 Q'ty/20cy (by sea) pcs 240 Q'ty/40cy (by sea) pcs 504 Dimension (L)(by sea) mm 1200 Dimension (W)(by sea) mm 1000 Dimension (H)(by sea) mm 2192 Net Weight (by sea) kg 271.2 Gross Weight (by sea) kg 288.94 Dimension & Weight (product) Product Dimension with Stand (WxDxH) (mm) 714 x 318 x 473 Product Dimension with Stand (WxDxH) (inch) 28.11 x 12.52 x 18.62 Product Dimension without Stand (WxDxH) (mm) 714 x 127 x 426 Product Dimension without Stand (WxDxH) (inch) 28.11 x 5. x 16.77 Stand Dimension (WxDxH) (mm) 634 x 318 x 371 Stand Dimension (WxDxH) (inch) 24.96 x 12.52 x 14.61 Weight (Net kg) 8. Weight (Net lbs) 17.64 Weight Without Stand (kg) 5.8 Weight Without Stand (lbs) 12.79 Dimension & Weight (box) Inside Carton Dimension (WxDxH) (cm) 97.5 x 18.5 x 51.3 Inside Carton Dimension (WxDxH) (inch) 38.39 x 7.28 x 20.2 Outer Carton Dimension (WxDxH) (cm) 99 x 20 x 53.6 Outer Carton Dimension (WxDxH) (inch) 38.98 x 7.87 x 21.1 Weight (Gross kg) 11.3 Weight (Gross lbs) 24.91 Accessories DisplayPort Cable 1 DisplayPort Cable Version 1.4 HDMI Cable 1 HDMI Cable Version 2.1 DVI Cable 0 DVI Cable Version NA USB Type A to Type B Cable 0 USB Type C to Type A Cable 0 USB Type C to Type C Cable 0 Thunderbolt Cable 0 VGA Cable 0 3.5mm audio Cable 0 3.5mm combo audio Cable 0 3.5mm Mic Cable 0 Power Cord 1 AC Adaptor 0 Quick Guide 1 Warranty Card 0 Mouse Bungee Unit 0 VESA Screw 4 Switch Case 0 Portable Screen Protection Case 0 Monitor Hood 0 Speaker (Accessories) 0 Model Info Series Name OLED Segment Name MAG Segment Name2 MAG 321CU Segment Name3 MAG 321CUP QD-OLED Barcode Info EAN 4711377250634
