ASUS LCD 32” PA32UCX-PK 3840x2160 ProArt 4K 3xHDMI DP REPRO HDR IPS MiniLED 1200 nits Ado

Popis produktu:

https://www.asus.com/Monitors/ProArt-Display-PA32UCX-PK/

https://www.asus.com/cz/events/infoM/activity_proart5years/



ASUS MT 32” PA32UCX-PK 4K HDR IPS Mini LED ProArt Display, 1200 nits, Off-Axis Contrast Optimization, 10 bit, Dolby Vision, HLG, 1152 zones, ?E < 1, 99% DCI-P3, 99.5% Adobe RGB, 100% sRGB/Rec. 709 , HWCalibration, TB3, Calman Ready, ColourSpace Integration

Panel Size: Wide Screen 32” (81.28cm) 16:9

Color Saturation : 89% Rec.2020, 99.5% Adobe RGB, 99% DCI-P3 and 100% sRGB

Panel Backlight / Type : Mini LED / IPS

True Resolution : 3840x2160

Display Viewing Area(HxV) : 708.48 x 398.52 mm

Display Surface : Non-glare

Pixel Pitch : 0.1845 mm

Brightness : 600 cd/? (Typical)/1200 cd/? (Peak)

Contrast Ratio : 1000 :1 (Typical)/1000000 :1 (HDR)

ASUS Smart Contrast Ratio (ASCR) : 100000000:1

Viewing Angle (CR?10) : 178°(H)/178°(V)

Response Time : 5ms (Gray to Gray)

Display Colors : 1073.7M (10bit)

Flicker free : Yes

LCD ZBD Warranty : Yes

HDR (High Dynamic Range) Support : Yes (HDR-10 /HLG (Hybrid Log Gamma)/Dolby Vision)

Dynamically Local Dimming : Yes, 1152 Zones

Off-axis Contrast Optimization (OCO) Technology : Yes

Video Feature

ProArt Preset : 13 Modes(Adobe RGB Mode/Rec. 2020/DCI-P3/DICOM/HDR_PQ DCI /HDR_PQ Rec2020/HLG/Dolby Vision/sRGB Mode/Rec. 709 Mode/User Mode 1/User Mode 2)

Color Temperature Selection : 5 Modes

Color Accuracy : ?E < 1

Gamma adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )

Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)

QuickFit (modes) : Yes (Alignment Grid/Paper/Ruler/Customization Modes)

Picture-in-Picture : Yes

Picture-by-Picture : Yes (support up to 4 UHD windows)

Low Blue Light : Yes

HDCP support : Yes, 1.4 & 2.2

Adaptive-Sync supported :Yes

Multiple HDR Mode : Yes

Audio Features

Stereo Speakers : 3W x 2 Stereo RMS

I/O Ports

Signal Input : Thunderbolt™ 3 USB-C™ x2 (In x1, Out x1), HDMI(v2.0b) x3, DisplayPort 1.2

Earphone jack : 3.5mm Mini-Jack

USB downstream : USB3.0 Type-A x3

Signal Frequency

Digital Signal Frequency : DisplayPort, Thunderbolt™ 3:142 KHz (H) / 40 ~60 Hz(V)

HDMI : 109 ~142 KHz (H) /29 ~65 Hz(V)

Power Consumption

Power On (Typical): < 58.67W*

Power Saving Mode : < 0.5W

Power Off Mode : 0W (Hard Switch)

100-240V, 50/60Hz

Mechanical Design

Chassis Colors : Black

Tilt : -5°~+23°

Swivel : -60°~+60°

Pivot : -90°~+90°

Height Adjustment : 0~130 mm

VESA Wall Mounting : 100x100mm

Frameless Design : Yes

Quick Release Stand Design : Yes

Security

Kensington lock

Dimensions

Phys. Dimension with Stand (WxHxD) : 727 x (470 – 600) x 240 mm

Phys. Dimension without Stand (WxHxD) : 727 x 426 x 93 mmBox Dimension (WxHxD) : 913 x 381 x 525 mm

Weight

Net Weight (Esti.) : 14.64 kg

Net Weight Without Stand (Esti.) : 9.7 kg

Gross Weight (Esti.) : 19.8 kg

Accessories

Thunderbolt™ 3 Cable

Power cord

DisplayPort cable

USB-C cable

USB-C to A cable

Quick start guide

HDMI cable

Warranty Card

Color pre-calibration report

Monitor hood

X-rite i1 Display Pro Calibrator

Compliance and Standards

BSMI, CB, CCC, CE, CEL level 0, CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, Mac Compliance, PSE, RoHS, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, RCM, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, ICES-3, PC recycle, VESA DisplayHDR 1000

Note

*measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection



Note1. HDR performance requires compatible monitors, streaming devices, video graphic cards, OS and playback software for PC devices or media players which all support HDR function.

Note2. The peak brightness 1200cd/? can only be triggered displaying HDR content that expresses the luminance value of greater than 1000 in a particular scene.
